• General Industry
• Oil & Gas

• Other Industries
• Upstream Exploration & Production
• Midstream Transportation
• Downstream Processing

• API 6D/6A
• ASME B16.34
• NACE MR0175
• API 6FA/API 607/API598

Size Range:

• 2 to 56 (API 6D Valves)

• 1 13/16″ to 16 3/4″ (API 6A Valves)

Pressure Class Range:

• Class 150 to 2500

• 2000 psi to 10000 psi

Seating Material:

Soft or Metal

• Increased efficiency enabled by independent ball and stem, which minimizes side thrust caused by pressure on the ball
• Improved safety assured by anti-static design that guarantees electrical continuity between all metallic components
• Simplified in-line inspection and maintenance made possible by top-entry design
• Compliance with the most severe pollution-control regulations owing to low-emission valves
• Used whenever it is required to perform maintenance activities without removing the valve from the line
• Less potential leakage paths than bolted bonnet side-entry valves

Standard

• Cast or forged components-bolted body design
• Seals: O-Ring + graphite fire safe
• Soft seated/Metal seated
• Fittings: Stem and seat greaser
• Self relieving or double piston effect seats
• Double block bleed
• Fire-safe
• Anti-static automatic
• Cavity relief

Cryogenic (-196 °C)

• Cast or forged components-bolted body design
• Seals: Lip-seal + graphite fire safe
• Soft seated/Metal seated
• Self relieving or double piston effect seats
• Double block bleed
• Extended bonnet
• Fire-safe
• Anti-static automatic
• Cavity relief

High Temperature

• Cast or forged components-bolted body design
• Seals: spiral wound or graphite
• Metal seated
• Self relieving seats
• Double block bleed
• Extended bonnet
• Fire safe
• Anti-static automatic
• Cavity relief
